Hive Specs
Hive Controller
The PassiveLogic Hive is the heart of our autonomous ecosystem, replacing traditional control panels.
Display
Size (diagonal)
10.1 in (256.54 mm) capacitive touch screen
Resolution
1920 × 1200 pixels
Slide-up touch screen
Screen opens to reveal 8 PassiveLogic Cell module bays and locks to protect wiring
Network
Wireless
Bluetooth range: up to 100 ft (30 m)
Ethernet
Stand-alone private network and isolated IoT network, 4-port industrial switch (10/100MB)
Connectivity Options
Protocols
BACnet/IP, Modbus TCP
Protocols w/Multi Cell
1-Wire protocol
Cell Module Bays
Cell module bays
8 Cell module bays, allowing different Cell modules to be mixed and matched by application
Multi Cell module
6 multi-function terminals, universal software-defined I/O
Relay Cell module
3 single-pole, single-throw, normally open relays
Powering the PassiveLogic Hive
Power draw
Up to 4A @ 24VAC nominal. Max load 98 VA. Use a Class II or Class III rated transformer dedicated to a single PassiveLogic Hive controller and grounded to a reliable earth ground.
Input voltage
24VAC, 16–20 AWG
Stripping length
5 mm
Environmental Operating Conditions
Operating temperature
-4 to 122°F (-20 to 50°C)
Storage temperature
-22 to 122°F (-30 to 50°C)
Mechanical
Height | Width | Depth
6.19 in (157.20 mm) | 9.39 in (238.56 mm) | 4.31 in (109.49 mm)
Weight
3.4 lb (1550 g)
Mounting Options
Surface mount
Mount with Hive Enclosure or other approved accessory. Use fasteners appropriate for the surface.
DIN rail mount
Mount with approved accessory. Make sure panel or enclosure has adequate ventilation. Use fasteners appropriate for the surface behind the DIN rail.
Wiring Example
Mechanical RTU control, valves, and temperature sensor
Multi Cell terminals are software-defined, so wiring placement is flexible.
Connected equipment
Rooftop unit (RTU), modulating actuator, floating point actuator, 10k ohm thermistor, power supply, and Hive Mini
Dimensions
